15mm thinness slim led driver 12v 15w dimmable led driver lifud

1 Piece
MOQ
$1.50(1 - 49 Pieces) $1.00(50 - 499 Pieces) $0.50(>=500 Pieces)
価格
15mm thinness slim led driver 12v 15w dimmable led driver lifud
特徴 ギャラリー 製品の説明 見積依頼
特徴
仕様
Features: 15mm thinness
Warranty(Year): 5-Year
Lighting solutions service: Lighting and circuitry design, Project Installation
Model Number: LKAD017V
Output Power: 6-15W
Output Type: Single
Input Voltage: 100-240Vac
Output Frequency: 50/60Hz
Output Current: 12Vdc/24Vdc 1250mA/625mA
証明: CE ROHS EMC LVD EU market
Size: 126*51*15mm
Efficiency: 90%
Type: LED driver
Protections: short circuit, overload, over voltage, over temperature
Output Mode: constant voltage 12/24V
degree of protection: IP20
Application: LED strip light
Product Name: slim led driver 12v 15w dimmable led driver lifud
基本情報
証明: CE ROHS EMC LVD EU market
Model Number: LKAD017V
お支払配送条件
Packaging Details: slim led driver 12v 15w dimmable led driver lifud 1pc pack in 1 inner box, 60pcs in 1 carton
Supply Ability: 10000 Piece/Pieces per Month
製品の説明
Product Description
What is a Constant Voltage LED Driver?
Constant voltage drivers are designed for a single direct current (DC) output voltage. Most common constant voltage drivers (or Power Supplies) are 12VDC or 24VDC. An LED light that is rated for constant voltage usually specifies the amount of input voltage it needs to operate correctly.
A constant voltage power supply receives standard line voltage (120-277VAC). This is the type of power that is typically output from your wall outlets around the home. Constant Voltage Drivers switch this alternating current voltage (VAC) to a low direct current voltage (VDC). The driver will always maintain a constant voltage no matter what kind of current load is put on it. Most often, constant voltage drivers are implemented in under-cabinet lights and other LED flex strip applications but it is not limited to those categories.
Product Features
When do I use a constant voltage LED driver?
With lighting in the real world, LEDs are usually used together in series and/or parallel circuits to create the desired outcome. Fortunately for lighting designers, manufacturers have introduced many LED products to the market that have multiple LEDs already assembled together like LED rope light, LED strips, LED bars, etc.
The most common LED strips are designed with a group of LEDs in series with a current-limiting resistor in line with them. The manufacturers make sure the resistors are of the right value and in the right position so that the LEDs on the strips will be less prone to the variation of the voltage source. Since their current is already being regulated, all they need is a constant voltage to power the LED(s).
When LEDs or an array of LEDs are constructed like this they will typically state a voltage to be run at. So if you see that your strip takes 12VDC, don’t worry about a constant current driver, all you will need is a 12VDC constant voltage source as the current is already being regulated by on board circuitry that the manufacturer has built in.
Product Paramenters
slim led driver 12v 15w dimmable led driver lifud
INPUT
Input Voltage
100-277VAC
Input frequency
50/60Hz
Power Factor
0.5
OUTPUT
DC Voltage
12V/24V
Rated Current
625mA/1250mA
Rated Power
6W-15W
SETUP Rise Time
<0.5s
PROTECTION
Short circiut
Recovers automatically after fault condition is removed
Overload
Overload protected @110-130% above peak rating
Over Temperature
Shut down o/p voltage . re-power on to recover
IP Code
IP20
ENVIRONMENT
Working TEMP.
-30-+50℃ (refer to output load derating curve)
Storage TEMP.
-40-+80℃
Safety & EMC
Safety Standards
CE
EMC Test Stardands
EMC
DIMENSION
126*51*15mm
Details Images
Certifications
Our products have TUV,CE,SAA,UL,FCC,CCC certifictes.
Installation Dimension
Installation Diagram
Related Products
Constant Voltage Triac Dimmable LED Driver for LED strips and LED Neons lights

Model:LKAD029DV

Input voltage:100-277Vac
Output Power: 30W
Output Voltage: 12/24Vdc
Output Current: 2.5A/1.25A
Dimming type: Triac Dimming led driver

Model:LKAD060V-TD

Input voltage:200-240Vac Output Power: 50W Output Voltage: 12/24Vdc Output Current: 4A/2A Dimming type: Triac Dimming led driver

Model:LKAD086V-T

Input voltage:100-277Vac Output Power: 60W-80W
Output Voltage: 12/24Vdc Output Current: 5A/2.5A Dimming type: Triac Dimmable led driver

Model:LKAD0100V-C

Input voltage:200-240Vac Output Power: 100W
Output Voltage: 12/24Vdc Output Current: 8A/4A Dimming type: Triac Dimming led driver

Model:LKAD160V-T

Input voltage:27100-277Vac Output Power: 150W
Output Voltage: 12/24Vdc Output Current: 16.5A/8.3A Dimming type: Triac Dimming led driver
Company Profile
About Linkuan Power
Guangdong Linkuan Smat Tech Co., LTD. (hereinafter referred to as Linkuan Smart), formerly known as Dongguan Linkuan Semiconductor Lighting Co., Ltd., was founded in 2007. It is located in Dongguancity, a famous manufacturing city in China.The company plant area is about 4500 square meters, the registered capital is 10 million yuan, the staff is about 150 people, inclduing 30 management, engineering and technical persons.The company has 4 automatic production lines, 2 wave soldering machines, 5 sets of automatic constant temperature burning-test equipment, ultrasonic wave equipment and other efficient production equipment.
Factory Show
R&D Ability
Our Team
Delivery
Fast Delivery
Samples orders: 1-3 days Less than 50pcs should be sample order to us
OEM orders: 7-10 days Avaialbe for quantity within 1000pcs and 80W LED drivers
FAQ
1) Question: When was LINKUAN Company established? Answer: Our company was established in 2005 with a registered capital of 30 million yuan. 2) Question: What is the main business of LINKUAN? Answer: Since 2005, the company has been committed to the research and development of LED controllers and dimmers. It currently holds a leading position in the field of LED control and dimmer control. Our products are compatible with Lutron, Dynalite, Clipsal, LDS, Helvar, Osram, Philips, ABB, Schneider, Leviton, JUNG, Brocade, Simon, Lichtregler, etc. 3) Question: What are the main products of LINKUAN? Answer: The collar products currently have DALI, 0-10V/1-10V, dmx512 controller, thyristor dimmer and other series of dimmers, dimming power supplies, and load controllers, high voltage, low voltage, constant current, constant Pressure LED lighting fixtures can be equipped with corresponding controllers. Can be used with or with the following brand products: Lutron, Dynalite, Qisheng, LDS, Helvar, Osram, Philips, ABB, Schneider, Leviton, JUNG, Brocade, Simon, Lichtregler Wait. 4) Question: Is the product of LINKUAN developed and designed by itself? What are the advantages? Answer: All of our products are self-developed and produced, and have their own intellectual property rights, and have won hundreds of national patents; our original digital dimming technology makes the dimming curve smooth and completely solves the stroboscopic and jitter problems; The products have been sold to more than 100 countries and regions around the world. 5) Question: What is the quality control system for LINKUAN? Answer: We strictly control quality according to ISO9001:2008. Since 2008, our ISO9001:2008 certificate has been issued by SGS from Switzerland. 6) Question: What certifications and products do we have? Answer: We mainly issue UL FCC TUV CE, CB, SAA, C-Tick, PSE, ETL, CCC and other certificates issued by SGS from Switzerland. Many products from Australia, Japan, and China can be converted into the customer's own country certificate through our CB certificate. 7) Question: How long is our product warranty? Answer: The crown products are subject to strict quality control. The product warranty for low-voltage input is 5 years, and the product warranty for high-voltage input (110-220V) is 3 years. 8) Question: How do I purchase a product that leads? Answer: Our headquarters is located in Dongguan, and Zhongshan has an office. Please tell us the products you are interested in and the quantity ordered, we will send you a quote as soon as possible. Our standard products have an inventory of 80,000 units. It is our consistent advantage to respond quickly to the needs of our customers. If the product is not in stock, we will deliver it within two to four weeks. Tel: +86 15899935775 WeChat: 15899935775 9) Question: What should I do if I have a problem after receiving the goods? Answer: Please describe the problem in detail. You may need to provide us with pictures of product connection and system settings. We will help you solve the problem as soon as possible. Incorrect connections and system settings are common problems. If our products have quality problems during the warranty period, they will be replaced free of charge

You are pleased to contact me directly if need my help
Nicole.Hu
Mobile: +86 15899935775
Wechat: Nicole-HYL05
Skype: Nicolekoalaa

Do you know the difference between constant current led driver power supply and constant voltage led driver power supply?

Today we will introduce to you the specific difference between constant current led driver power supply and constant voltage led driver power supply and the principle of constant current led driver power supply. Constant current led driver power supply and constant voltage led driver power supply play an important role in people’s production and life, so many people are concerned about these two Nouns are not unfamiliar.
Although the constant current led driver power supply is not as widely used as the constant voltage led driver power supply, it still plays a very important role in people's lives. The output current of a constant current led driver power supply is fixed and will not change due to changes in voltage, that is to say, it is a led driver power supply with a stable current. The operating principle of the constant current led driver power supply is not complicated, it mainly lies in the feedback of the output current, and after the feedback, the conduction state is changed by adjustment, so as to ensure the constant ratio of the voltage to the resistance in the loop, which is what we call current Constant. All in all, the constant current led driver power supply has the characteristics of not changing with the change of the output voltage, not changing with the change of the working environment, and having infinite internal resistance.
Then talk about the difference between constant current led driver power supply and constant voltage led driver power supply. First of all, the biggest difference between the two is that the output current of the constant current led driver power supply is a constant fixed value, while the output voltage of the constant voltage led driver power supply is a constant fixed value. For a constant current led driver power supply, under any size of load voltage, its load current will not change; for a constant voltage led driver power supply, its load voltage will not change under any size of load current. Therefore, current constant current led driver power supplies are generally used in LED drivers, while constant voltage led driver power supplies are more widely used. The batteries and dry batteries in our lives are DC constant voltage led driver power supplies. In addition, the most common 220V AC power in our lives , Belongs to the AC constant voltage led driver power supply. In other words, there are two main differences between the constant current led driver power supply and the constant voltage led driver power supply. On the one hand, it is its operating principle, and on the other hand, it is the scope of its application in people's lives. With the increasing application of smart lighting, our company has developed constant current dimming led driver power supply and constant voltage dimming led driver power supply.
